How to Self-Host Penpot with Docker on Ubuntu 24.04

Penpot gives you a browser-based workspace for interface design without putting every design file in a hosted service. Installing it involves more than starting the editor: the backend must save files, and the exporter must turn your design into a usable image.

This guide helps you install Penpot 2.17.2 with Docker on Ubuntu 24.04. You will create a local account, draw a small design, reopen it, and export it. Access stays private through an SSH tunnel, so you do not need a domain to complete the installation.

Before you start

Use an Ubuntu 24.04 VPS with 4 vCPUs, 6 GB RAM, sufficient free disk space for the images and your designs, and a sudo-capable SSH account. You also need a current desktop browser and SSH client on your computer. Replace ubuntu and SERVER_IP in the tunnel command with your own login and server address.

This is a fresh, single-server installation. It uses Penpot’s frontend, backend, and exporter images, with PostgreSQL and Valkey. The database and design assets have persistent Docker volumes. It is not a high-availability setup, and a hosted design tool is simpler if you do not want to manage a server.

Install Docker and prepare the files

On a fresh Ubuntu server, install Docker and the Compose plugin:

$ sudo apt-get update
$ sudo apt-get install -y docker.io docker-compose-v2 curl
$ sudo systemctl enable --now docker
$ sudo docker version
$ sudo docker compose version

If Docker is already installed from another supported source, keep that installation and check that docker compose version works. Do not mix package sources just to repeat this block.

Create the project directory and a private environment file:

$ mkdir -p ~/penpot
$ cd ~/penpot
$ touch .env
$ chmod 600 .env

Create two different random secrets in your password manager: a 128-character hexadecimal string for Penpot and a 64-character hexadecimal string for PostgreSQL. Edit ~/penpot/.env with these two lines, replacing both placeholders with the generated values:

PENPOT_SECRET_KEY=REPLACE_WITH_128_RANDOM_HEX_CHARACTERS
POSTGRES_PASSWORD=REPLACE_WITH_64_RANDOM_HEX_CHARACTERS

Do not use the placeholder text as a secret. Keep this file private and retain it with the installation: the backend and exporter need the same Penpot key, and the database password must remain consistent.

Create ~/penpot/compose.yaml with these contents:

x-common: &common
  PENPOT_PUBLIC_URI: http://localhost:18094
  PENPOT_FLAGS: >-
    disable-registration disable-email-verification
    disable-secure-session-cookies disable-telemetry
    enable-prepl-server disable-onboarding

services:
  penpot-frontend:
    image: penpotapp/frontend:2.17.2
    restart: unless-stopped
    ports:
      - "127.0.0.1:9001:8080"
    volumes:
      - penpot_assets:/opt/data/assets
    environment: *common
    depends_on:
      - penpot-backend
      - penpot-exporter

  penpot-backend:
    image: penpotapp/backend:2.17.2
    restart: unless-stopped
    volumes:
      - penpot_assets:/opt/data/assets
    environment:
      <<: *common
      PENPOT_SECRET_KEY: ${PENPOT_SECRET_KEY:?Set PENPOT_SECRET_KEY}
      PENPOT_DATABASE_URI: postgresql://penpot-postgres/penpot
      PENPOT_DATABASE_USERNAME: penpot
      PENPOT_DATABASE_PASSWORD: ${POSTGRES_PASSWORD:?Set POSTGRES_PASSWORD}
      PENPOT_REDIS_URI: redis://penpot-valkey/0
      PENPOT_OBJECTS_STORAGE_BACKEND: fs
      PENPOT_OBJECTS_STORAGE_FS_DIRECTORY: /opt/data/assets
    depends_on:
      penpot-postgres:
        condition: service_healthy
      penpot-valkey:
        condition: service_healthy

  penpot-exporter:
    image: penpotapp/exporter:2.17.2
    restart: unless-stopped
    environment:
      <<: *common
      PENPOT_SECRET_KEY: ${PENPOT_SECRET_KEY:?Set PENPOT_SECRET_KEY}
      PENPOT_INTERNAL_URI: http://penpot-frontend:8080
      PENPOT_REDIS_URI: redis://penpot-valkey/0
    depends_on:
      penpot-valkey:
        condition: service_healthy

  penpot-postgres:
    image: postgres:15
    restart: unless-stopped
    environment:
      POSTGRES_DB: penpot
      POSTGRES_USER: penpot
      POSTGRES_PASSWORD: ${POSTGRES_PASSWORD:?Set POSTGRES_PASSWORD}
    volumes:
      - penpot_postgres:/var/lib/postgresql/data
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U penpot"]
      interval: 5s
      timeout: 5s
      retries: 10

  penpot-valkey:
    image: valkey/valkey:8.1
    restart: unless-stopped
    healthcheck:
      test: ["CMD", "valkey-cli", "ping"]
      interval: 5s
      timeout: 3s
      retries: 10

volumes:
  penpot_postgres:
  penpot_assets:

The shared x-common settings keep the browser address consistent across services. The flags disable the optional onboarding survey and enable the container-local management server needed for account creation. PENPOT_PUBLIC_URI is the URL you will open on your computer; its name does not make the service publicly accessible. Only the frontend publishes a port, and that port listens on the VPS loopback address.

Keep PENPOT_INTERNAL_URI pointing to the frontend’s Docker service name. The exporter runs inside Docker and cannot use your computer’s localhost tunnel to reach the editor.

Start the services and create your account

Validate the configuration, download the images, and start the stack:

$ sudo docker compose config --quiet
$ sudo docker compose pull
$ sudo docker compose up -d
$ sudo docker compose ps

The first start initializes PostgreSQL and runs backend migrations. Wait for the database and Valkey health checks to pass, and check that the other services remain running. Read the backend logs if initialization is still in progress:

$ sudo docker compose logs --tail=50 penpot-backend
$ curl -I http://127.0.0.1:9001

Expect HTTP 200 from the frontend. That response is only the first check; it does not prove that file saving or export works. Create your first account through Penpot’s supported management command:

$ sudo docker compose exec penpot-backend python3 manage.py create-profile

Enter the email address, name, and password when prompted. The password prompt does not echo what you type. There is no default account to leave active. Browser registration stays disabled in this setup.

Open Penpot and save a small design

On your own computer, start the tunnel in a separate terminal:

$ ssh -N -o ExitOnForwardFailure=yes -L 127.0.0.1:18094:127.0.0.1:9001 ubuntu@SERVER_IP

Leave that terminal open and visit http://localhost:18094 in your browser. Log in with the account you just created. Do not browse to the VPS’s public port 9001; it is intentionally unavailable directly.

In Drafts, choose + New File. Double-click the file name at the top left and rename it Installation check. Select Board (B) and drag on the canvas to make a board. Use Rectangle (R) to draw inside it, then Text (T) to add Penpot works. Give the rectangle a visible fill so the exported result is easy to recognize. This small fixture is enough to test the installation; you do not need to build a full interface.

Wait for the saving indicator beside the file name to finish before leaving the file. Click Drafts to return to the dashboard, reopen Installation check, and confirm that the board, rectangle, and text remain. Reload once more if necessary to distinguish saved content from what is still in the browser’s memory.

Export and verify the result

Select the board in Layers, scroll to Export in the right-hand panel, and click Add export (the plus button). Leave PNG at 1x, choose Export 1 element, and open the downloaded file. Check that it contains the expected rectangle and text, not a blank canvas or error page. To check vector export as well, change the format dropdown from PNG to SVG and export again.

Our TeamCompute test exported a 600 × 360 board as a 5,322-byte PNG in 4.60 seconds, measured from clicking Export until the browser download was saved. The image contained the colored rectangle and text. The SVG also had a 600 × 360 viewBox and included the expected text. These are functional observations, not a rendering-speed benchmark.

These checks exercise different parts of the stack. Reopening the file checks saved design data; a PNG export also exercises the exporter service. A working login screen alone cannot confirm either result.

Keep the file private while testing. Open its ordinary editor URL in a separate browser session that is not logged in but still has access through the tunnel. It should ask for a login rather than reveal the design. Sharing a prototype is a separate action, not part of this installation check.

If something does not work

• Login does not appear or keeps failing: check that the account-creation command completed, that the backend is running, and that the browser URL exactly matches PENPOT_PUBLIC_URI.
• The browser cannot connect: keep the SSH terminal open and ensure local port 18094 is free. If you change that port, update PENPOT_PUBLIC_URI and apply the configuration again.
• The editor works but PNG export fails: inspect the exporter logs with sudo docker compose logs --tail=50 penpot-exporter. Keep its internal URI on the Docker frontend address, and check that all Penpot images use the same version.
• Services restart or initialization stalls: inspect memory, disk space, and service logs. Do not delete the named volumes as a troubleshooting shortcut; they contain the database and design assets.

You now have a private Penpot installation with a saved design and a checked export. Closing the SSH tunnel disconnects your browser, but it does not stop the services on the VPS.
